Midmark 204 - Step 2: Connect power cord; Level table; Electrical Requirements; Optional: Reversing the Side Drawers; Side Drawer Reversal Procedure

2
Electrical Requirements:
204 (-001 thru -004) & 604 (-001 thru -003) / 115VAC
Dedicated Supply Circuit: 115 VAC, 50/60 Hz, 15 amp
204 (-006 & -007) & 604 (-005 & -006) / 230VAC
Dedicated Supply Circuit: 230 VAC, 50/60 Hz, 15 amp
To reverse the side drawers...
A) Remove side panel.
B) Remove drawer fronts.
C) Install drawer fronts on opposite side.
D) Install side panel on opposite side.
Note: To remove side panel, pull panel out from bottom.
To remove drawer fronts, pull tabs down to release.
Step 2: Connect power cord / Level table.
A) Connect power cord(s) to facility receptacle*.
B) Adjust two leveling feet under head-end of table.
*Note: Some models have two power cords. Both cords must be
connected for proper operation
MA8094i
Leveling Foot
(Optional)
Reversing the Side Drawers - 604 only
The side drawers can be reversed so that they open from the opposite side of the table.
MA8095i
Tabs
