Operation
Models 224, 225, 626, & 627
Step 2:
A) Press Chair Up on hand control to raise
chair height.
B) Insert Install Assist Tool legs into spline
receptacles.
C) Press Chair Down on hand control to lift
the chair base to desired height.
Step 1: Slide spline adapters onto
Install Assist Tool legs.
Spline
Adapter
To remove Install Assist Tool legs...
A) Press Chair Up on hand control to lower chair base to floor or dolly.
B) Lift up on spline adapter release lever.
C) Slide Install Assist Tool legs from spline receptacles.
Release
Lever
