CHAPTER 5 WIRING
AUDIO AMPLIFIER LED INDICATOR TABLE
Designation
LED 1
Wl)
LED 2
VW
Location
Upper Center
Nearest C3
Lower Center
Near U2 & U6
Function
Fault Indicator
Fault Indicator
Red
Red
State / Meaning
/
Blinking
Overload (note 2)
I
Notes:
1. Active output protection circuit. To reset circuit, clear fault and switch off power.
2. Blinking caused by either intermittent audio overload or overheating. LED is only supposed to blink
during start-up.
WHEEL DRIVER LED INDICATOR TABLE
Designation
Location i
Function Color State Meaning
1
LED 1 Right Center
I Indicator
Nearest C5 & P2
Notes:
1. The regulated power supply voltage source is monitored by LED 1, which should remain lit non-stop
Blinking or failure to illuminate indicates an intermittent connection, power problem, circuit fault, etc.
