Midwest Shorty - Sub Assembly B Disassembly (Motor Housing)

Number
Part
Number
Description
1 40443A Speed Change Collar (2-Speed)
2 40443 Speed Change Collar Screws
3 40493 Clutch Housing
4 40493A 2-Speed Clutch
5 40437B Drive Plate (shown with Bushing Posts (40460 &
Bushings 40461) Also note: the Clutch Pins (40459) are
inserted as well.
6 40494A Spindle Bolt
7 40437A Wide Drive Ring Spindle
8 40437 Wide Drive Rings
9 40449 Main Spindle
10 40432 Main Spindle Bearing
11 40464 Thrust Washer
12 40464B Metal Shim
13 40448 Loading Springs
Sub Assembly B Disassembly (Motor Housing)
(Note: most pictures are of a 40446 1-speed raceway, not the correct 40446A raceway)
STEP 9
After removing the two narrow drive rings, insert your
turbine raceway tool (00003) into the three holes in the
raceway. Unscrew the raceway from the housing. If you
cannot get the raceway to unscrew, put the threads of the
