en - Areas of application
22
Before placing pipettes in the injector unit, please make sure that
all hollow sections are free of blockages.
Before loading the machine and before starting a pro‐
gr
amme
– Check that the mobile unit is correctly connected to the water sup‐
p
ly in the washer-disinfector.
Loading pipettes
This mobile injector unit has three injector manifolds which must be
loaded as follows:
Row Max. length
[mm]
Qty Volume [ml]
1 550 10 10 to 100
2 500 14 10 to 25
3 440 14 1 to 10
Pipettes must not extend beyond the sides of the mobile injector unit.
Inser
t the pipettes into the funnels with the pointed end facing
downwards.
F
it the top ends of the pipettes into the relevant holders on the sup‐
port rail.
