Installing several ProLine elements
47
Calculating the worktop cut-out
The frames of the ProLine elements overlap the worktop at the outside right and
left by 8mm on each side.
 Add up the widths of the ProLine elements and subtract 16mm from this figure.
Example:
288mm + 288mm + 380mm = 956mm - 16mm = 940mm
The ProLine elements are 288mm, 380mm or 576mm wide depending on
model (see “Building-in dimensions”).
Spacer bars
When installing several ProLine elements, an additional spacer bar must be fitted
in between the individual ProLine elements. The position for securing the spacer
bar will depend on the width of the ProLine element.
Installation with a downdraft extractor
Please refer to the separate “Downdraft extractor with CombiSet” instruction
manual for details about worktop cut-out dimensions and fitting spacer bars.
