The paper protective sheet protects the
extension piece from being scratched
when the tower is being fitted. It is
removed when fitting is complete.
Fold the protective sheet at the top.
Remove the protective foil from
around the sticking points.
Stick the protective sheet to the ex-
tension piece so that it is smooth at
the sides and flush at the bottom.
Fitting the tower
Before fitting remove the protective
foil.
A protective cardboard sheet protects
the tower from accidental scratching
during fitting.
Remove the protective foil from
around the sticking points.
Attach the protective sheet to the
front of the tower so that it protrudes
slightly below the bottom edge.
Installation
32
