Use 3.5 x 16 mm screws to secure
the cooker hood to the wall unit on
both sides at the lower edge of the
body.
19 mm thick unit sides:
16 mm thick unit sides:
Using the 3.5 x 16 mm screws se-
cure the cooker hood to the wall unit
on either side as shown. Use
washers with 16 mm unit sides.
Installation
23
