Press the facia strips into their
holders according to the thickness of
the side walls. Observe the markings
on the rear of the facia strips.
Depth alignment
Units deeper than 285 mm require the
fitting of a spacer bar to prevent va-
pours collecting between the rear of
the cooker hood and the wall.
Adjust the spacer bar to the appro-
priate depth along the required
breaking point.
Fit the spacer bar on the guide rail lo-
cated on the rear lower edge of the
body.
Installation
24
