^ Lift the appliance up into the housing
from below, and engage in the
brackets.
Note for dismantling the cooker hood:
Undoing the screws on the left and
right inside the housing releases the
brackets, allowing the appliance to
be removed from the unit.
^ Push the cooker hood back against
the spacer strip.
^ Pull out the deflector plate.
^
Secure the appliance to the brackets
using 2 screws on each side.
^
Remove the protective film between
the deflector plate and the casing.
Installation
23
