Technical data
34
Fan motor* 120 W
Cooktop lighting 2 x 50 W
Total rated load* 220 W
Voltage, frequency AC 230 V, 50 Hz
Fuse rating 10 A
Mains connection cable length 1.5 m
Weight
DA 396-6 21 kg
DA 399-6 26 kg
DA 399-6 EXT 24 kg
Extraction power* according to EN 61591, extraction ducting 125/150 mm
Setting 1 130/150 m³/h
Setting 2 230/250 m³/h
Setting 3 330/350 m³/h
Intensive setting 450/500 m³/h
Recirculation power**
Setting 1 100 m³/h
Setting 2 150 m³/h
Setting 3 250 m³/h
Intensive setting 350 m³/h
* For EXT models, the rated load and extraction power will depend on the type of external
motor fitted.
Length of connection cable to external motor: 1.9 m
**Recirculation mode with conversion kit DUW 20 and charcoal filter DKF 12 (optional
accessories)
