Installation
*INSTALLATION*
39
6 screws 5 x 60 mm and
6 plugs 8 x 50 mm
for securing the rangehood to the wall.
The screws and wall plugs are
designed for use in solid walls only.
For other types of wall construction,
alternative fixings are required.
Make sure the wall is able to take the
weight of the rangehood.
2 M6 locknuts
for securing the appliance
2 screws, 3.9x7.5mm
for securing the chimney
Montage
Installation
Montaje
Montaggio
Montering
Montagem
Asennus
Installation plan
See the installation plan for details on
the individual steps involved in the
installation of this appliance.
Conversion kit for recirculation
mode
The conversion kit contains an exhaust
grille, hose, and hose clips (not
supplied, but available as an optional
accessory. See “Technical data”).
