Miele DA 4288 W - Safety Distance (S)

Installation
*INSTALLATION*
41
a
Exhaust air
b
Recirculation
c
Ventilation grille positioned at the top for recirculation
de
Installation area (onlyd is required for recirculation mode). Wall and ceiling
area for the vent cut-out, for fitting the wall socket and for feeding the
connection cable through to the external motor for EXTA models. For
recirculation mode, only a wall socket needs to be fitted.
Exhaust connection150mm
Safety distance (S)
The minimum distances between the cooking surface of a cooktop (pan
support(s) for gas models) and the bottom of the rangehood are as follows,
unless a greater distance is specified by the manufacturer of your cooking
appliance. See also “Warning and Safety instructions”.
Cooking appliance Minimum distance S
Electric cooktop 600mm (AU, NZ)
450mm
(HK, MY, SG, TH, TW)
Electric grill, deep fat fryer (electric) 650mm
Multi-burner gas cooktop with maximum 45.4MJ/h
total output, with no burner having a greater output
than 16.2MJ/h.
650mm
Multi-burner gas cooktop with total output greater
than 45.4MJ/h, but with a maximum of 77.8MJ/h,
with no burner having a greater output than
17.3MJ/h.
760mm
Multi-burner gas cooktop with total output greater
than 77.8MJ/h, with a single burner having a
greater output than 17.3MJ/h.
Not possible
Single burner gas cooktop with a maximum output
of 21.6MJ/h.
650mm
Single burner gas cooktop with an output greater
than 21.6MJ/h, but with a maximum of 29.2MJ/h.
760mm
Single burner gas cooktop with an output greater
than 29.2MJ/h.
Not possible
