If you have put locking pins into the
hinges to stop the door opening too far:
^
Remove the locking pins from the top
of the hinges.
To remove the soft-close mechanism
^
Place the door with the outer side
downwards on a stable surface.
Warning. The soft-close mechanism
snaps shut when dismantled.
Danger of injury.
^
Unscrew mounting b and pull
soft-close mechanism c downwards
to remove it.
^
Undo ball joint d using a spanner
and remove it.
^
Stand the appliance door up, and
loosen the hinges at the front (the
hinges remain open).
^ Remove screws a, and use stoppers
supplied c to plug the empty holes.
Do not close up the hinges. Danger
of injury.
^
Refit the hinges on the diagonally
opposite side of the door b.
Use a power screwdriver to secure
the hinges - screws a are
self-tapping.
Changing the door hinging
40
