Installationsplan G 7856
Stand: 19.01.2004
Seite 4
4. Voltage (as supplied) V/Hz AC 208/60
Rated load kW 5.8
Fuse rating A 2 x 30
Anschlusskabel, Querschnitt mindestens mm² 3 x AWG10
Length of supply lead (H05(07)RN-F) without plug
m 1.9
Voltage V/Hz 3 AC 208/60
Rated load kW 5.8
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 4 x AWG12
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.9
5. Voltage (as supplied) V/Hz 3 AC 208/60
Rated load kW 5.8
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 4 x AWG12
Length of supply lead (H05(07)RN-F) without plug m 1.9
Voltage V/Hz AC 208/60
Rated load kW 5.8
Fuse rating A 2 x 30
Connection cable, min. cross-section mm² 3 x AWG10
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.9
6. Voltage (as supplied) V/Hz 3 AC 220/60
Rated load kW 6.4
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug m 2.3
Voltage V/Hz 3N AC 380/60
Rated load kW 6.4
Fuse rating A 3 x 16
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 2.3
7. Voltage (as supplied) V/Hz 3N AC 380/60
Rated load kW 6.4
Fuse rating A 3 x 16
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug m 2.3
Voltage V/Hz 3 AC 220/60
Rated load kW 6.4
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 2.3
8. Voltage (as supplied) V/Hz 3 AC 200/50
Rated load kW 5.4
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug m 2.3
9. Voltage (as supplied) V/Hz 3 AC 200/60
Rated load kW 5.4
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug m 2.3
