Installationsplan G 7856
Stand: 19.01.2004
Seite 3
Technical datasheet
Commercial dishwasher G 7856
Legend:
Circled, bold-type abbreviations:
Connection required
Abbreviations surrounded by broken circle:
Connection optional or required, depending on model
Electrical
connection
1. Voltage (as supplied) V/Hz 3N AC 400-415/50
Rated load kW 9.1-9.7
Fuse rating A 3 × 16/3 × 15
Connection cable, min. cross-section mm² 5 × 2.5
Length of supply lead (H05(07)RN-F) without plug m 1.7
Voltage V/Hz 2N AC 400-415/50
Rated load kW 6.2-6.6
Fuse rating A 2 × 16/2 × 15
Connection cable, min. cross-section mm² 5 × 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.7
Voltage V/Hz AC 230-240/50
Rated load kW 3.3-3.5
Fuse rating A 1 × 16/1 × 15
Connection cable, min. cross-section mm² 5 × 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.7
Voltage V/Hz AC 230-240/50
Rated load kW 6.2-6.6
Fuse rating A 1 × 30
Connection cable, min. cross-section mm² 3 × 4.0
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 2.1
Country variations:
2. Voltage (as supplied) V/Hz 3N AC 400/50
Rated load kW 7.0
Fuse rating A 3 x 16
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
Voltage V/Hz 3 AC 230/50
Rated load kW 7.0
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.7
3. Voltage (as supplied) V/Hz 3 AC 230/50
Rated load kW 7.0
Fuse rating A 3 x 20
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
Voltage V/Hz 3N AC 400/50
Rated load kW 7.0
Fuse rating A 3 x 16
Connection cable, min. cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
Convertible
m 1.7
