There must be a distance of at
least 20 cm between the floor and
the bottom of the “Waterproof” unit
housing, for either vertical or hori-
zontal installation.
If the stopcock is situated in the
worktop, a special angle connector
can be ordered from the Miele Spare
Parts Dept. (Part No. 2078910).
Lay the hose in such a way that it
does not rise above the bottom of
the “Waterproof” unit casing (see il-
lustration).
Plumbing
72
