G 600 Series Dishwashers
Full size models G 643 - G 663
Removing the leg extensions
The black leg extensions can be
removed to reduce the machine height
to 32
1
/
4
" - 33" (819-838 mm) (see
Inset).
A = Black leg extension (removable)
B = White leg (must be installed on
machine).
^ After removing the black leg
extensions, screw the white legs onto
the dishwasher.
Machine heights of 33
1
/
4
" - 34"
(845-864 mm) are not possible using
the supplied legs.
For this height range, or for heights
greater than 34
7
/
8
" (886 mm),
extended legs (part # 02 702 601)
are necessary.
Contact the Miele Technical Service
Department for the appropriate legs.
Product and Cut-out Dimensions
9
