Miele KFN 37692 iDE User Manual

Cleaning and care
59
 C
arefully remove, the ice cube draw‐
er, which will be full of water. Empty
and clean it.
The ice cube tray c
annot be removed
and must be cleaned in situ.
 Dr
y the ice cube tray  with a soft
cloth.
When the ice cube maker is switched
back on aga
in, the ice cube tray will
rotate back into the original position.
Cleaning the ice cube tray
Clean the ice cube tray,
– befor
e switching off the ice cube
maker for a long time
– regularly, to remove ice and water
residues.
If you have previously selected the
setting
"Rinse the ice cube maker"
(see "Rinsing the ice cube maker"),
the ice cube tray will already be in the
cleaning position.
The ice cube tray  ca
nnot be re‐
moved and must be cleaned in situ. To
clean the tray you need to move it into
the cleaning position.
Selecting the cleaning position
The setting can only be selected if
the
ice cube maker is switched on.
 Empty the ic
e cube drawer.
 T
ouch the settings sensor.
All symbols available for selection will
appear in the display and the 
symbol
flashes.

Miele KFN 37692 iDE Specifications

General

Door hinge	Right
Control type	Sensor
Product color	White
Reversible doors	Yes
Appliance placement	Built-in
Door panel included	No
Noise level	38 dB
Climate class	SN-ST
Total net capacity	248 L
Total gross capacity	- L
Lamp type	LED
No Frost (fridge)	-
Fridge net capacity	180 L
Number of vegetable drawers	2
Fridge number of shelves/baskets	3
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	68 L
Freezer number of shelves/baskets	4
Storage time during power failure	20 h
Cord length	2.1 m
Current	10 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	226 kWh

Weight and Dimensions

Depth	545 mm
Width	559 mm
Height	1770 mm
