Miele KM 2012 - Page 45

Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
45
Safety distances to the sides and
back of the hob
Ideally the hob should be installed with
plenty of space on either side. There
may be a wall at the rear or a tall unit or
wall on one side (right or left) (see illus-
trations).
Minimum distance between the back
of the worktop cut-out and the rear
edge of the worktop:
50mm
Minimum distance between the
worktop cut-out and a wall or tall unit to
the right of it:
100mm.
Minimum distance between the
worktop cut-out and a wall or tall unit to
the left of it:
100mm.
Not allowed
Highly recommended
Not recommended
Not recommended
