KM 463 / KM 468 / KM 469
Ceramic hob
Control area
a Double circle zone
bd Single circle zone
c Extended cooking zone (Multi-zone)
e Control area
f Cooking zone controls and displays
g Hob ON/OFF
h Safety lock
j Switching on the outer circle of the
double circle zone or the extended
cooking zone
Indicator lights for:
i Safety lock
k Switching on the outer circle of the
double circle zone or the extended
cooking zone
Guide to the appliance
6
