Program data
Operating data module
Program data
Delete data e
\ A
^
Select "Program data".
The display shows:
Operating data module ~ Program data
1 Hot W. / Cot. extra dry 0 %
2 Hot Wash / Cottons dry 0 % e
\ A
^
Select the desired program from the
program list.
^
Press the jog shuttle to list all program
starts of the program "1 Hot wash / Cotton
dry plus" with date and start time.
Program data ~ 1 Hot W. / Cot. extra dry
Date: 05.21.2004 Start time: 11:30am
Date: 05.21.2004 Start time: 12:30pm e
\ A
^ Select the desired program start from the
list of all program starts of program "1 Hot
wash / Cotton dry plus" and press to
confirm the selection.
Program data ~ 1 Hot W. / Cot. extra dry
Date: 05.21.2004 Start time: 11:30am
Name: Smith e
\ A
Additional selections
Installation site: New York
Serial number: 12345678
Machine type: PT 7331
Laundry load: 13 lb
Button +: pressed
Program start: 11:30 am
Program finish: 12:05 pm
Total running time: 0 hr 35 min
Electrical energy: 12.5 kWh
Gas energy: 0 kWh
Steam energy: 0 kWh
Program change: 2
(The last 3 stops and starts are
shown after selecting and pressing the jog shuttle.)
Program errors: none (only the last 3 errors are
shown)
Area 1: Drying
Block 1: Pre-drying
Process type: Residual moisture
Process value: 15 %
Actual residual moisture: 15 %
Run time: 6 min
Max. Exhaust air temperature: 162 °F
Max. Supply air temperature: 252 °F
Area 1: Drying
Block 2: Drying
Process type: Residual moisture
Process value: 0 %
Actual residual moisture: 0 %
Run time: 6 min
Max. Exhaust air temperature: 172 °F
Max. Supply air temperature: 280 °F
Area 2: Cooling down
Block: Cooling down
Process type: Cooling down
Process value: 50 %
Actual temperature: 122 °F
Run time: 3 min
Max. Exhaust air temperature: 126 °F
Max. Supply air temperature: 203 °F
Residual moisture: -3 %
Optional modules
21
