a Emergency stop switch
Press the red button to switch the machine
off.
b Control panel
c Detergent dispenser drawer
Pull the handle to open the compartment.
d Drum door
Pull the door handle to open the drum door.
Do not use force to open it.
e Door handle
The door handle is fitted with a safety device
to ensure that the door lock functions
correctly (see page 29).
f Service panel
g Plinth
Description of the machine
M.-Nr. 06 572 495 9
f
a
b
d
c
e
g
