a
Communication module slot
The XKMRS232 communication module is available as an optional
accessory.
b
Electrical connection
c
2x hard water connection
(Optional)
d
Cold water connection
e
Hot water connection
Water temperature to maximum 70°C.
f
Cold water connection for liquid dispensing
g
Connections for external dispenser pumps
For up to 12 dispenser pumps.
h
Vapour extraction/free outlet TypeAB
i
Drain valve
Connection for plastic pipe HTDN70.
