External drainage of condensed water
The machine is fitted with a non-return
valve as standard to prevent water from
flowing back into the machine (eg. if
the machine is connected to a siphon).
Close the water inlet port above the
condensed water container with the
bottom part of the rubber plug. The
plug must face towards the interior
of the machine so that the con-
densed water container can easily
be inserted.
Connection to wash basin drain outlet
Push the hose clip (1) and knurled
nut connector (2) (from the sink drain
outlet) over the drain hose.
Put the adapter sleeve (3) supplied
into the hose.
Screw the drain hose to the drain out-
let with the knurled nut connector.
Tighten the hose clip (1) up close to
the nut (2).
