Installation and connection
43
Installation conditions requiring a
non
-return valve
There is a risk of back-flow into
the dryer if a non-return valve is not
fitted.
Back-flow could damage the dryer
and also
the room in which it is
located.
Certain installation conditions, such
as those
described below, require
the fitting of a non-return valve.
Installation conditions requiring the
fitting of a non-return valve:
– Drainage into a sink or floor gully
wher
e the end of the hose is
immersed in water.
– Connection to a sink drain outlet.
– Connection to a drainage system
alr
eady in use by another appliance,
e.g. a dishwasher or washing
machine.
Maximum delivery head with non-return
valve: 1.00 m
Example: Connection to a sink drain
outlet
The drain hose with non-return valve
fitt
ed can be connected directly to a
suitable sink drain outlet.
Remove the following from the back
of the dryer at the top: Adapter 1 and
hose clip 3 behind it.
