Removing the transit fittings
^
Remove the packaging and position
the washing machine where you want
to use it.
^ Unscrew and remove the 4 outer
screws marked A.
^ Unscrew the 4 screws marked B.
These screws must then be left on
the transit bars (see illustration).
^
Remove the transit bars.
^ Plug the 4 large holes with the caps
supplied.
The transit bars and screws should
be stored in a safe place for future
use. They need to be re-fitted if the
machine is ever moved again (e.g.
when moving house).
Re-fitting the transit fitting
^ Re-fitting is carried out by reversing
the procedure given above.
Installation
49
