Plumbing
Connection to the drainage system
The machine drains via a drain pump
with a delivery head of 1 metre.
The hose must not be kinked as this re-
stricts drainage. The swivel elbow at
the end of the hose can be turned in
either direction, or can be detached if
required with a sharp twist and pull.
Drain hose dimensions:
Length . . . . . . . . . . . . . . . . . . . . 1.5 m
Interior diameter . . . . . . . . . . . . 22 mm
Exterior diameter . . . . . . . . . . . . 30 mm
Exterior diameter
of the hooked section . . . . . . . . 32 mm
Drain hose connection:
Direct into a sink: Hook the hose
over the edge and secure. Make
sure that the water can flow freely to
avoid flooding and to prevent water
from being sucked back into the ma-
chine.
Connected to a standpipe.
Connected to a plastic drain pipe
with a rubber nipple. There is no
need to use a non-return valve.
Allow the water to drain off into a
floor drain.
If required, the hose can be extended
to a length of 5 m.
For a delivery head of more than 1 m
(up to a maximum of 1.8 m) a second
Duo drain pump is available with the
corresponding conversion kit from the
Miele Spare Parts Department.
40
