Connection to the drainage
system
The machine drains via a drain pump
with a delivery head of 1 metre.
The drain hose is 1.5 m long. It must
not be kinked as this restricts drainage.
The swivel elbow at the end of the hose
can be turned in either direction, or can
be detached if required, with a sharp
twist and pull.
Drain hose connection:
1. Direct into a sink.
Please note the following
–
Hook the hose over the edge and
secure.
–
Make sure that the water can drain
away freely without hindrance.
Otherwise there is a risk of water
overflowing or of some of the drained
water being sucked back into the
machine.
2. Connected securely to a plastic drain
pipe with a rubber nipple. There is no
need to use a non-return valve.
3. Connected securely to a standpipe.
4. Connected securely to a floor gully.
If required the drain hose can be
extended to a length of 5 metres. The
accessories required can be
purchased from the Miele Spare Parts
Dept.
For draining the water away with a
delivery head over 1 metre (and up to a
max. of 1.8 metres) a 2nd "Duo-drain
pump" is available together with the
corresponding kit from your Miele
Dealer or the Miele Spare Parts Dept.
Installation and connection
65
