9
4. Pull 6”-12” of film from the bottom roll. Pass it under the lower idler bar. Drape the film from the bottom roll over
the film from the top roll. See figure 5.
FIGURE 5
NOTE: The shiny side of the film must always go against the heat shoes.
The heat shoes reach a temperature of up to 350°F. Do not touch the surface of the heat shoes.
5. Turn the Motor Switch to forward to start the Laminating and Pull Rollers.
6. Feed a piece of thin cardboard about 10” x 25” against the film so that it is centered between the two heat shoes.
Push the cardboard and film into the laminating rollers. See figure 5. Watch cardboard pass through the back (pull)
rollers to avoid a wrap-around.
To Next Page
