10
7. When the feed card has completely exited the pull rollers at the rear of the laminator turn the motor switch off.
8. Replace the feed table.
9. If you are ready to laminate, the heat switch should be in the on position.
Adjusting Mandrel/Film Tension…..
Each type of laminating film has different characteristics and may require laminator adjustment. The tension should be
set so that the film moves over the heat shoes without wrinkles as the film enters the laminator. Best results are
obtained if tension adjustments are made while the unit is at operating temperature. If any adjustments are required use
the following procedure:
1. Switch the heaters on. Wait for the heat shoes to reach operating temperature.
2. Press the motor switch to on.
3. Locate the knob on the right side of the top supply mandrel. See Figure 1. Turn the knob to adjust the tension
(clockwise to increase, counter clockwise to decrease) until the film passes over the top heat shoe without wrinkles and
the web between the laminating and pull rollers is tight. Note: This adjustment requires only a few degrees of turn. If
the knob is turned too far, you may stall the drive motor.
4. If necessary locate the knob on the right side of the bottom supply mandrel and adjust the tension as in step 3 above.
5. If you are not ready to laminate, turn the motor switch and heat switch off.
Setting Heat Shoe Temperature...
The laminator temperature should be adjusted according to the film thickness and the item being laminated. Contact
film manufacturer for recommended temperature settings. Keep in mind that the temperatures listed are approximate
and different brands of laminating film and heavy paper stocks may require different temperatures. Also keep in mind
that when the machine is cold the warm-up time may be longer than the heat indicator light may suggest due to the
rollers not yet having sufficient heat distribution.
Use the heater controllers on the left side of the laminator to adjust the temperature of the heat shoes. Use the
temperatures in the table below as a guide.
Material Temperature Range
1.5 mil (.0015”) 270°F - 325°F
3 mil (.003”) 260°F - 275°F
5 mil (.005”) 250°F - 270°F
10 mil (.010”) 250°F - 270°F
