Migo One360 - Installation of the Child Car Seat; Group 0+;1 (rearward facing)

EN
INSTALLATION OF THE CHILD CAR SEAT
A
C
B
3
1
2
Group 0+ / 1 (reward facing)
(For children from 0-18 kg)
• If there is no Isox system on the vehicle, use
the 3-point harness of the car.
• Pull the car‘s seat belt to the maximum
length.
• Guide the seat belt through the blue belt
guide on the rear top of the child car seat.
• Guide the lap belt through both side guides,
under the comfort insert.
• Close the seat belt with the buckle on the
car seat. Make sure that the seat belt is not
twisted.
• Tighten the vehicle‘s seat belt as much as
possible and check that the child car seat is
securely positioned.
• ATTENTION: The rearward-facing position,
secured by the vehicle‘s 3-point belt, is
ONLY permissible for group 0+.
• Press both side Isox connector buttons to
extend the Isox connectors in length.
• Insert the Isox connectors into the insertion
aids and press until they click into place.
• The display on both sides only turns green
when the connections are made. Pull the
child car seat towards the backrest until it
stands securely.
• Take the Top-Tether out of the pocket.
• To release the Top-Tether, press the grey
adjustment button with one hand and pull
the side of the belt anchor to the required
length with the other hand.
• Pull the upper belt through the belt guide
marked blue on the headrest.
• Attach the anchor to the attachment point
on the rear of the car seat.
• Tighten the top tether by pulling on the
other side of the strap. Make sure the indi-
cator is green.
