Water softenening devices, type Smart B65 are ones of high quality and precision. Properly installed and
operated, the Smart B65 devices guarantee infallible operations and increased durability. Please read
this manual carefully before assembly. This manual serves as future reference to system operations.
Water softener, model Boy B65 can be installed everywhere, where the flow rate of water is not higher
that 75l/min** and the water temperature is lower than 40°C. The highest quality of components
installed in Mijar products guarantees their infallible functionality for many years.
Technical Parameters:
Technical Parameters:
System capacity for 10°dH: [litres] 1500
Sal consumption per regeneration: [kg] 0.7
Flow rate (nom/max): [l/min] 0-20*/75**
Pressure: [bar] 1.5-6.0
Connections: [cal] 3/4”
Maximum temperature of water: [°C] <40
Brine tank capacity: [kg] 10
Amount of resin: [l] 5
Power supply: [V] 230
Height: [mm] 620
Width: [mm] 240
Depth: [mm] 440
*water softened completely
*water softened completely
**water softened partially, only for valves type B65.
Counting the system's capacity for different water hardness:
The system capacity is counted using formula:
z=1500 x 10/y
where:
z-
z-
amount of water softened between regenerations.
amount of water softened between regenerations.
Y-
Y-
tested water hardness in °dH (Germann degrees of hardness)
tested water hardness in °dH (Germann degrees of hardness)
EXAMPLE
EXAMPLE
of counting the system capacity.
of counting the system capacity.
Data:
Data:
tested water hardness: 15 °dH
tested water hardness: 15 °dH
using formula:
→
→→
→z=1500 x 10/15 we receive the result of
→
→→
→z=1500 x 10/15 we receive the result of
10
10
00 litres.
00 litres.
With a water hardness of 15°dH, the Smart B65 system will soften 1000 liters of water.
