•Manual initiation of regeneration process (rys 1.)
To manually initiate the regeneration process, the user has to turn the knob (7) clockwise until REGEN is
shown in the gap. The know (7) will turn and when the regeneration process is finished, the knob will
reach the (IN SERV) position. Thank to the built-in water mixer, during the regeneration mode hard
water is available.
Rys. 1 Control Valve.
3. ASSEMBLY AND INITIATION OF THE SYSTEM:
Before initiating the device, the user must set the current time and the day of regeneration
(see point 2).
The valve is set to carry out the regeneration every 6 days at 2:00 am by default.
Connecting the device: (pic. 2)
1.Connect inlet (B) and outlet (C ) of the device to the water supply.
1.Connect one side of the draining elastic hose 1/2”, to the fitting (A) and the other to the sewage
system. The sewage system should be unobstructed enough to discard 5 l/min of rinse water. The
elastic hose should be inflexible enough to rule out the possibility of cloggs, which can lead to overflow
of brine tank.
2.Slowly turn on raw water supply valve .
3.Pour approximately. 45kg of tablet salts into the brine tank
4.Deaerate system by turning the knob 7 (rys.1) clockwise to the BACK WASH position. After few
minutes the system will deaerate. Next, turn the knob back to the IN SERV position and the system will
go back to water softening mode
5.Pour about 5 liters to the brine tank .
6.Connect the device to power supply 230V (D) and set the current time (see point 2)
PIC. 2 Device connections.
4.HANDLING THE DEVICE:
The proper handling of the device requires periodic tablet salt refill.
The brine tank should be fully refilled every time. The minimum amount of salt that must be in the tank
