MikroTik Chateau 5G Quick Start

Integrated Wireless module operating at 2.4 GHz, 802.11b/g/n protocol. Antenna gain 3 (dBi).
Integrated Wireless module operating at 5 GHz, 802.11a/n/ac protocol. Antenna gain 5.5 (dBi).
Mounting
The device is designed to be used indoors, by placing it on the desktop.
Powering
The device accepts power from an adapter:
Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-28 V DC.
The power consumption under maximum load can reach 17 W, with attachments 23 W.
Configuration
We recommend checking for updates frequently to receive the latest updates for your RouterOS software to ensure the best performance and stability.
RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to
the possibilities: . In case an IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC https://mt.lv/help https://mt.lv/winbox
address of the device from the LAN side (all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device for reinstallation, see section .Buttons and Jumpers
Mode button
Mode button located on the back of the unit, to the right side.
The Default configuration for the Mode button is dark mode - to turn off all LEDs. The button can be configured in RouterOS to run any user-specified
scripts.
Sync button
Sync button located on the top of the unit. WPS Sync button, if configured on the wireless interface, can be used to connect new clients.
Press and hold the WPS button for 1 – 5 seconds to enable WPS for wireless interfaces.
Front LED status
Wireless network activity. Ethernet port activity. Power-on. 5G signal strength.
We recommend using Cat5 shielded cable. When using and installing this device please pay attention to the Maximum Permissible Exposure
(MPE) safety distance with a minimum of 20 cm between the radiator and your body.

MikroTik Chateau 5G Specifications

General

Operating temperature (T-T)	-40 - 70 °C
Certification	CE, EAC, ROHS
Mean time between failures (MTBF)	200000 h
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	4 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	2
Antenna gain level (max)	4 dBi
Product type	Tabletop router
Product color	Black, White
Sustainability certificates	RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	44 mm
Width	240 mm
Height	156 mm
