MikroTik Chateau 5G Quick Start

Removing back cover to access PCB
In case there is a need to access PCB, the back cover can be removed.
Remove center screw;
Use a small screwdriver to pry open backplate in marked spots;
Continue to pry it open by going up;
At the end lift off the whole backplate.

MikroTik Chateau 5G Specifications

General

Operating temperature (T-T)	-40 - 70 °C
Certification	CE, EAC, ROHS
Mean time between failures (MTBF)	200000 h
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	4 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	2
Antenna gain level (max)	4 dBi
Product type	Tabletop router
Product color	Black, White
Sustainability certificates	RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	44 mm
Width	240 mm
Height	156 mm
