The device accepts power with the following modes:
Passive 10-30 V PoE to Ethernet port. The Higher voltage needed to compensate for power loss on long cables. At least 18 V is suggested.
Direct input to the power jack 10-30 V.
Maximum power consumption 11 W.
Booting process
RouterOS is the operating system of all RouterBOARD routers. Please see documentation here: https://mt.lv/help
This device is not preconfigured other than an IP address on the Ethernet port. Another configuration has to be applied according to the documentation
manual linked above.
The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address
of 192.168.88.1 with the username admin and no password.
In case you wish to boot the device from the network, for example, to use MikroTik Netinstall, hold the reset button of the device when starting it until the
LED light turns off, and the device will start to look for Netinstall servers.
In case the IP connection is not available, the Winbox utility can also be used to connect to the MAC address of the device. More information in the
documentation.
Extension slots and ports
One gigabit Ethernet port (With Auto MDI/X so you can use either straight or cross-over cables for connecting to other network devices). The
Ethernet port accepts 10-30V DC powering from a passive PoE injector.
miniPCIe slot for either an 802.11 wireless card or a 3G/LTE modem. SIM slot is available for miniPCIe 3G/LTE modems and has no functionality
when a modem is not installed.
Buttons and jumpers
RouterBOOT reset button has the following functions:
Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (total 5 seconds).
Keep holding for 5 more seconds, LED turns solid, release now to turn on CAPs mode (total 10 seconds).
* Keep holding the button for 5 more seconds until LED turns off, then release it to make the RouterBOARD look for Netinstall servers (total 15
seconds).
Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.
Useful for RouterBOOT debugging and recovery.
Specifications
For more information about this product, specification and pictures please visit our web page: https://mikrotik.com/product/m11g
Operating system support
The device supports RouterOS software version 6. The specific factory-installed version number is indicated in the RouterOS menu /system resource.
Other operating systems have not been tested.
