the height is displayed on the summary line. Press to find additoinal information
6. Tilt measurement
1) Tilt measurement
Press button，the symbol appears in the function field, press to take
the inclination and the distance.
The inclination sensor measures tilts between ± 45°.
During the measurement of tilt, the instrument should be held without transverse tilt,
as far as possible within ± 10°. The accuracy is 0.3°.
2) Auto horizontal measurement
Press twice ，the symbol appears in the functional field. Press button to
measure angel and distance, The summary line displays the result as the direct horizontal
distance
3) Auto height measurement
Press third times ，the symbol appears in the functional field. Press button
to take both sloping sides, the vertical height is displayed in the summary line.
4) Triangular measurement
Press four times ，the symbol appears in the functional area. Press button
to take 3 sloping sides respectively, the area is displayed in the summary line. Press
to find out each angel of the Triangular and circumference.
7. Edit Measuring data Function
Note: this function is only enabled in measurement mode and at least a measured data
display in the screen.
1) Select data
Press or to select measuring type in measuring process file (left handside of the
screen) , press to locate the corresponding data, the data frame turning yellow
indicates the data has been selected.
2) Re-measure:
When this data was selected, press to re-measure the distance till the result is
satisfied. Press or return to measurement interface,
3) Adjust measurement result:
