Operator's Manual: Millcreek 27+ & 37+ Spreaders
A-5
Axle, Wheel and Safety Shield Assembly (continued)
Item # MC Part # Qty Component Description
1 215120 1 Left Wheel
215263 1 Right Wheel
2 261898 2 Ratcheting Hub (includes bushings 210100)
3 215358 2 Keyed Hub
4 220207 2 1/4 x 1-1/4 Clevis Pin
5 34385 2 3/32 x 3/4 Cotter Pin
6 215359 2 Pawl
7 220201 2 Torsion Spring
8 210456 1 54 Tooth Sprocket
9 210227 2 1-1/8" 2 Bolt Flanged Bearing
10 34387 2 1/4 x 2-1/2 Cotter Pin
11 210466 2 1/4 x 2 Key
12 210130 2 1/4 x 1 Key
13 261779 1 Axle Shaft
14 261771 1 Cam Wheel
15 261874 1 Front Shield
16 261869 1 Left Side Shield 27
261891 1 Left Side Shield 37
17 261738 1 Rear Guard Bar
18 261868 1 Right Side Shield 27
261872 1 Right Side Shield 37
19 34386 8 1/2 x 1 Lug Bolt
20 34006 4 3/8 x 1 Carriage Bolt
21 34392 10 3/8 Wide Flange Nut
22 34414 2 1/4 SAE Washer
23 34099 12 5/16 Flange Nut
24 34274 7 5/16 x 3/4 Carriage Bolt
25 34366 1 5/16 x 3 Carriage Bolt
26 34409 4 5/16 x 3/4 Set Screw
27 215314 2 Cast Corner
28 34215 3 5/16 x 2 Square Head Set Screw
29 34020 1 5/16 Nut
30 34290 1 5/16 x 3/4 Square Head Set Screw
31 34136 4 5/16 x 1/2 Flange Bolt
