Operator's Manual: Millcreek 27+ & 37+ Spreaders
A-7
Apron Chain Drive Group (continued)
Item # MC Part # Qty Component Description
1 261739 1 Right Side Apron Bracket
2 210436 2 5 Tooth Sprocket
3 261772 1 Apron Shaft
4 261754 1 Left Side Apron Bracket
5 220104 2 Pawl Spring
6 261830 2,1 Pawl
7 261911 1 Cam Roller Arm
8 261748 1 Ratchet
9 261829 1 Short Crank Arm
10 261916 1 Cam Roller
11 220105 1 Ratchet Spring
12 261756 2 Side Link Guide
13 261867 1,0 Long Linkage 27
261871 0,1 Long Linkage 37
14 261832 1 Short Linkage
15 220138 1 Front Lever Spring
16 261818 1 Left Side Lever
17 261884 0,1 Roller Arm Mounting Bracket
18 261900 0,1 Drive Pawl 37
19 210124 0,2 3/4" Shaft Collar
20 220199 1 1/4 x 2-1/4 Clevis Pin
21 220204 3 Wire Locking Clip
22 34218 2,1 3/8 x 1-1/2 Carriage Bolt
23 34392 4 3/8 Wide Flange Nut
24 34391 4 3/8 Center Locking Nut
25 34198 1 1/2 Thin Nylon Locking Nut
26 34227 4 1/2 Washer
27 34202 1,0 3/8 x 2-1/4 Bolt
28 34006 0,1 3/8 x 1 Carriage Bolt
29 34314 1 1/4 x 1/2 Carriage Bolt
30 34099 8,11 5/16 Flange Nut
31 34337 7,8 5/16 x 1/2 Carriage Bolt
32 34412 1,2 5/16 x 3-1/2 Carriage Bolt
33 34390 1 3/8 x 3-1/2 Carriage Bolt
34 34219 1 3/8 x 2-1/2 Carriage Bolt
35 34018 2,3 3/8 Washer
36 34141 1 3/8 Lock Washer
37 34087 1 3/8 Nut
38 34410 2 3/16 x 1-1/2 Key
39 210129 1 3/16 x 1 Key
40 34282 0,1 5/16 x 1-1/2 Carriage Bolt
41 34413 0,1 3/8 x 2 Carriage Bolt
42 34223 0,1 5/16 Nylon Locking Nut
43 34201 1,2 3/4 Washer
44 34409 2 5/16 x 3/4 Set Screw
45 34057 2 5/16 Washer
46 34092 2 1/4 Flange Nut
47 34124 1 1/4 Nylon Lock Nut
48 34245 1 1/4 x 1-1/4 Carriage Bolt
49 220210 1 Rubber Cap
50 34422 1 3/8 x 1-3/4 Carriage Bolt
