Operator's Manual: Millcreek 27+ & 37+ Spreaders
A-9
Beaters and Drive Assembly (continued)
Item # MC Part # Qty Component Description
1 261837 1 Right Side Lever
2 220199 1 1/4 x 2-1/4 Clevis Pin
3 220204 5 Wire Locking Clip
4 261866 1 Linkage 27
261870 1 Linkage 37
5 261864 1 Guide Bracket
6 261865 1 Lift Arm
7 220171 1 Chain Tensioner Spring
8 261855 1 Idler Bracket
9 210433 2 15 Tooth Idler Sprocket
10 261828 1 Lift Arm Mounting Bracket
11 220105 1 Long Spring
12 210463 1 27 Chain (#50 x 122 Links)
210464 1 37 Chain (#50 x 151 Links)
13 210455 1 10 Tooth Sprocket
14 210106 2 3/4" 2 Bolt Flange Bearing
15 261744 1 Beater
16 210128 1 3/16 x 3/4 Key
17 34392 10 3/8 Wide Flange Nut
18 34375 1 3/8 x 3 Carriage Bolt
19 34191 1 3/8 x 3/4 Carriage Bolt
20 34219 1 3/8 x 2-1/2 Carriage Bolt
21 34218 1 3/8 x 1-1/2 Carriage Bolt
22 34337 4 5/16 x 1/2 Carriage Bolt
23 34099 4 5/16 Flange Nut
24 34227 2 1/2 Washer
25 34391 1 3/8 Center Locking Nut
26 34018 4 3/8 Washer
27 34252 1 3/8 x 1-3/4 Bolt
28 34422 1 3/8 x 1-3/4 Carriage Bolt
29 280262 2 Idler Bushing
30 261899 1 Rubber Hose
31 34306 2 1/4 x 1/4 Set Screw
32 34057 7 5/16 Washer
33 220210 1 Rubber Cap
34 268334 1 Lifter Arm Spacer
35 34247 1 3/8 x 3-1/4 Carriage Bolt
