1 [DRUM IN L, R]
1/4" jack sockets to connect the e-drum module (left and right channel)
2 [AUX IN]
1/4" jack socket to connect a mixer or playback device
3 [DRUM VOLUME]
Volume control for the e-drum channels
4 [AUX VOLUME]
Volume control for the AUX channel
5 Rotary controls to adjust the frequencies
[BASS] Control to adjust the low frequencies
[MIDDLE] Control to adjust the mid frequencies
[TREBLE] Control to adjust the high frequencies
6 Power indicator LED
Lights up when the device is turned on and operational.
7 [POWER]
Mains switch. Keep the [POWER] button pressed for a few seconds to turn on / o the device.
If the device receives no signal for 20 minutes, it automatically switches to standby mode. Turn on the device using the
[POWER] button.
Connections and operating elements
DM-30
15
E-Drum Monitor
