You have the option to change the MIDI note assigned to a pad. To do so proceed as follows:
1. Press [MODE] repeatedly until the [VOICE] LED lights up.
2. Hit the respective pad to activate it.
3. Press [PAGE] repeatedly until the display shows the assigned MIDI note in the ‘Nxx’
format.
4. Adjust the number using [–] and [+] (setting range: 0 to 99).
The setting is automatically stored.
The following table shows the MIDI mapping in default setting.
No. Name Assigned MIDI note
1 Crash 1 49
2 Tom 1 48
3 Tom 2 45
4 Tom 3 43
5 Ride 51
6 Kick 36
7 Snare 38
Adjusting assigned MIDI note
Operating
MPS-150
27
E-Drum Module
