1 Adjust the height of the rack’s horizontal crossbar and three wing arms
according to your preferred playing position. Then tighten the retaining
screws.
2 Position the two feet on the floor and insert the two rack legs into the
holder clamps provided for this purpose. Make sure that the lower ends of
the legs are resting flush on the floor. Then tighten the retaining screws.
3 Position the holder clamps for the individual pads. Then tighten the
retaining screws.
4 Turn the L-rods into a suitable position for mounting the pads. Then
tighten the retaining screws.
5 Insert the crash pad, ride pad and hi-hat pad supports into the respective
holder clamps on the rack. Secure the supports at the desired vertical
position using the retaining screws.
6 Loosen the retaining screws at the support joints and orient the supports
so as to match your preferred playing position. Then re-tighten the
retaining screws.
Setting up the rack
Assembly
e-drum set
10
