Millenium MPS-750X PRO - Hi-hat Mounting on Rack

Mounting the hi-hat on the rack
=
<
;
:
8
9
1. Open the legs (23) so that the hi-hat stand is stable.
2. Push the forks of the bass drum pedal (24) into the holes on the base of the stand.
3. Screw the rod (25) clockwise into the thread.
4. Attach the tube (26) to the upper end of the stand so that the rod (25) protrudes from the tube.
5. Adjust the height of the tube (26), tighten the wing nuts of the fastening clamps and push the support (27) over the tube so
it is resting on the rod (25)
6. Push the hi-hat cymbal onto the tube. Leave enough space between the support and the cymbal so that you can control
the opening and closing of the cymbal.
7. Tighten the screws on the clasp (28) of the hi-hat cymbal.
Assembly
14
MPS-750X PRO
E-Drum Set
