Millenium MPS-750X PRO - Assembly; Assembly Overview

4 Assembly
Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specied sequence. The
nal positions of the components are shown in the illustration below.
ö # $ %
&
'
( ) *
1 Drum module
2 Hi-hat pad with pedal (13 inch)
3 Crash pad (15 inch, dual zone, with choke function)
4 Tom pad (10 inch, dual zone, mesh head)
5 Tom pad (12 inch, dual zone, mesh head)
6 Ride pad (18 inch, triple zone, with choke function)
7 Snare pad (13 inch, dual zone, mesh head)
8 Bass drum pad (18 inch) with bass drum pedal
9 Ground tom pad (14 inch, dual zone, mesh head)
Assembly
MPS-750X PRO
9
E-Drum Set
