4 Assembly
Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specied sequence. The
nal positions of the components are shown in the illustration below.
0
/
-
,
3
2
1
0
,
6
4
+
10 Tom pad 1 (8"), tom pad 2 (8")
11 Tom pad 3 (10"), tom pad 4 (10"), snare pad
12 Hi-hat controller
14 Hi-hat pad
15 Crash 1, crash 2
16 Ride
17 E-drum module Millenium MPS-850
18 Hi-hat stand with pedal
19 Bass drum pad pedal
21 Bass drum pad
Assembly
10
MPS-850
E-Drum Set
