Millenium MPS-850 Assembly Instructions

Assembling the hi-hat stand
Assemble the hi-hat stand as shown below.
Proceed as follows to attach the hi-hat controller (12) and the hi-hat (14) to the hi-hat stand (18):
1. Loosen the Allen screw on the hi-hat connector piece with the drum key. Turn the top anti-clockwise and lift up the indi‐
vidual parts to remove them.
2. Put the hi-hat on the lower part of the connector piece. Put the parts removed in the previous step back onto the connector
piece and tighten the Allen screw again.
3. Put the hi-hat controller onto the hi-hat stand.
4. Place the hi-hat with the connector piece onto the hi-hat stand. The distance between the hi-hat and the hi-hat controller
should be 15 mm to 20 mm.
5. Tighten the wing screw on the connector piece.
15-20 mm
Positioning the bass drum and hi-hat
1. Place the pedal with the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
2. Place the hi-hat pedal to the left of the bass drum pad.
Assembly
MPS-850
15
E-Drum Set

Millenium MPS-850 Specifications

General

Configuration	5-piece
Hi-Hat	10" Hi-Hat Pad
Effects	Reverb, EQ
Sequencer	Yes
Bluetooth	No
Headphone Output	Yes
Aux Input	Yes
Type	Electronic Drum Set
Tom 3	8" Dual-Trigger Pad
Hi-Hat Controller	Yes
Drum Module	MPS-850 Module
USB	Yes
Outputs	Stereo Out, Headphone Out
Inputs	Aux Input
Pads	Mesh Pads
MIDI	USB-MIDI
Power Supply	9V DC
