Miller 1025 - Features and Controls

1
Features and Controls
Fig. 2
Fig. 1
Sliding Platform Camera Screws Camera Plate
Tilt Lock
Tilt Drag Control Bubble Level
Pan Drag Control
Counterbalance
Selector
Quick Release Knob
Safety Tab
Pan Handle Sliding Platform Lock
Pan Handle Clamp
Threaded Stud
Clamp Nut
Pan Lock
