Miller 1025 - Technical Data

3
Arrow 40 Arrow 55
Weight - kg (lb) 3.2 (7.0) 3.2 (7.0)
Payload Range - kg (lb) 7.0 – 16.0 (15.4 – 35.3) 10.0 – 25.0 (22.0 – 55.1)
Max Capacity - kg (lb) 25 (55.1) 25 (55.1)
Tilt Drag 7 Selectable fluid drag positions + 0 7 Selectable fluid drag positions + 0
Tilt Range + 90
o
/ -75
o
+ 90
o
/ -75
o
Tilt Lock Positive Lock calliper brake system Positive Lock calliper brake system
Pan Drag 7 Selectable fluid drag positions + 0 7 Selectable fluid drag positions + 0
Pan Range 360
o
360
o
Pan Lock Positive Lock calliper brake system Positive Lock calliper brake system
Counterbalance System 4 Selectable positions (see Fig. 7) 4 Selectable positions (see Fig. 8)
Camera Platform Type Quick release sliding platform Quick release sliding platform with
with 70 mm travel. 100 mm travel.
Camera Plate 1⁄4”, 3/8” 1⁄4”, 3/8”
Mounting Base Ø100 mm Ball Levelling Ø100 mm Ball Levelling
Ball Level Range 15
o
15
o
Handle Telescopic black anodised pan handle Telescopic black anodised pan handle
with adjustable reach and angle. with adjustable reach and angle.
Temperature range -
o
C(
o
F) -40
o
to +65
o
(-40
o
to +149
o
) -40
o
to +65
o
(-40
o
to +149
o
)
Construction Lightweight diecast Aluminium alloy, Lightweight diecast Aluminium alloy,
moulded reinforced plastics moulded reinforced plastics
Sealing Water & Dust resistant Water & Dust resistant
Finish Matt black (low sheen) durable powder Matt black (low sheen) durable powder
coated with anti-corrosive pre treatment coated with anti-corrosive pre treatment
Warranty 3 Years 3 Years
